JW51 Series Water Jet Loom

JW51 Series Water Jet Loom

This product is mainly aimed at providing a practical solution for users of water-jet looms. This type of water jet loom can adopt a variety of configurations to meet the needs of different users and is suitable for weaving light- and medium-density fabrics.

This product is mainly aimed at providing a practical solution for users of water jet looms. This type of water jet loom can adopt a variety of configurations to meet the needs of different users and is suitable for weaving light- and medium-density fabrics.

Main Features:

  1. The rigid frame structure, composed of multiple braces and box wall panels, provides the foundation for high-speed and stable weaving.
  2. Can be installed with a single pump or double pump, and features an intelligent electric control system to enable free selection of two-color or four-color weft.
  3. Compatible with mechanical or electronic weft storage devices.
  4. Warp let-off and take-up systems can be mechanical, electronic, or a combination; with electronic winding, weft density control is achieved.
  5. High-speed water pump system enables high-speed and stable weft insertion.
  6. Can be equipped with crank shedding, cam shedding, dobby shedding, or jacquard shedding.
  7. The intelligent control system, independently developed by the company, enables convenient and user-friendly operation of all machine parameters through an intuitive human-machine interface.
  8. Reed width series (cm):170, 190, 210, 250, 280, 340.
